Schneider Solid Insulated Switchgear

Mv gas insulated switchgear gis cbgs 0 sf6 circuit breaker switchgear ratings features up to 38 kv 2 000 a 31 5 ka and 150 kv bil compact design 24 w for mains feeders and 48 w for tie fixed vacuum or sf6 circuit breaker solid insulated and shielded bus bar system internal arc tested 31 5 ka 1 s per iec 62271 200.

Schneider solid insulated switchgear.

2sis creates a three layered system medium voltage conductive layer epoxy insulating layer and grounded shield layer throughout the entire switchgear that optimizes performance and increases life expectancy. Air insulated switchgear motor starters gas insulated switchgear ring main unit rmu shielded solid insulation system transformers 20 ka 1s cas 36 630 switch fuse sf6 indoor fixed compact and modular switchgear combining all mv functional units internal arc classification iac a fl 20ka 1 sec 25 ka 1s fbx 630 circuit breaker fuse vacuum. Cbgs 0 uses a grounded and shielded solid insulated bus system installed in the top rear part of the switchgear outside the sf6 gas compartment allowing for system changes without gas handling on site. Safety reliability flexibility from traditional air and gas insulated switchgear to the innovative shielded solid insulation system 2sis schneider electric offers a variety of medium voltage switchgear line ups to suit your specific switching control and production needs.
